Model No.:
CM30E / CM60E / CM120E
Fire protection performance:
Base material grade A; cloth grade B / C processable flame retardant.
Product features:
Patented easily mounting solution; Zero formaldehyde emission meets International EO standard. This new design functions much better than the older type by the more precise frame, Eco-friendly, flame retardant and moisture proofing. M-softpack solves the older type whose sound absorbing function is sacrificed at least 10% because of the resin solidified frame.
Application:
Conference rooms, recording rooms, studios, multi-functional halls, and large auditoriums to control the reverberation time.
Consumption:
Refer to acoustic design
Environmentally friendly base materials
Base Material:
80kg/m³ high structure micropore white fiber glass wool
Frame:
Light high-strength metal frame
Finish:
Acoustic cloth (Grade A/B/C); Can be made Imagine Spray Painting
Right angle
Chamfer
Model No.:
CM30 / CM60 / CM120
Fire protection performance:
Base material grade A; cloth grade B / C processable flame retardant.
Product features:
Patented easily mounting solution; Zero formaldehyde emission meets International EO standard. This new design functions much better than the older type by the more precise frame, Eco-friendly, flame retardant and moisture proofing. M-softpack solves the older type whose sound absorbing function is sacrificed at least 10% because of the resin solidified frame.
Application:
Conference rooms, recording rooms, studios, multi-functional halls, and large auditoriums to control the reverberation time.
Consumption:
Refer to acoustic design
Base Material:
80kg/m³ high structure micropore yellow fiber glass wool
Frame:
Light high-strength metal frame
Finish:
Acoustic cloth (Grade A/B/C); Can be made Imagine Spray Painting
Right angle
Chamfer
Common Size：
Each edge ≥300mm ≤2400mm
Thickness 30mm / 60mm / 120mm
Absorption Coefficient：
