Quality sound absorption that traps echoes effectively.
Made from purely natural green fibre acoustic wool, this EQ Walleasear is also high-density enough to meet all your acoustic requirements. It provides amazing sound pressure that does a great job of absorbing broadband frequencies through its back cavity design.
Versatile features that make a difference.
It can serve either as a diffusing wall or as a low frequency trap. It controls main reflections and has a double bandwidth ratio of 1 (Absorption):1 (Diffusion). If you want a superb acoustic treatment that doubles for you, this product is the best choice. It’s the perfect choice for use in studios, hallways, and even classrooms!
Model:
Right angle: EQ30T / EQ60T / EQ120T
Chamfer: EQ30TD / EQ60TD / EQ120TD
Selection of colors:
Base material:
Purely natural green fiber acoustic wool
Frame:
Sound reflection resistant design; anti-oxidization treatment; patented aluminum profile
Finish:
Linen double density composite acoustic cloth.
Acoustic Structure:
Three layers of base material in different densities wrapped in the airtight frame, forming an acoustic cavity to absorb sound in broadband frequency.
Eco-friendly:
Zero Formaldehyde emission; E0 standard
Common size & weight:
Size for thickness 30mm
1800mm (H) x 600mm (W) – 5.2kg
1200mm (H) x 600mm (W) – 3.5kg
600mm (H) x 600mm (W) – 1.8kg
1800mm (H) x 300mm (W) – 2.7kg
1200mm (H) x 300mm (W) – 1.8kg
300mm (H) x 300mm (W) – 0.5kg
Size for thickness 60mm
1800mm (H) x 600mm (W) – 7.5kg
1200mm (H) x 600mm (W) – 5.1kg
600mm (H) x 600mm (W) – 2.6kg
1800mm (H) x 300mm (W) – 3.8kg
1200mm (H) x 300mm (W) – 2.6kg
300mm (H) x 300mm (W) – 0.7kg
Size for thickness 120mm
1800mm (H) x 600mm (W) – 14kg
1200mm (H) x 600mm (W) – 9.4kg
600mm (H) x 600mm (W) – 4.7kg
1800mm (H) x 300mm (W) – 7.4kg
1200mm (H) x 300mm (W) – 4.9kg
Installation:
Come with standard anti-resonance velcro fixing system.
Sound absorption coefficient:
Wider panel that efficiently works in a number of ways.
The Walleasear EQ50B offers a much wider panel than the EQ30T. It’s perfect for absorbing sound in all frequencies and can function either as a low frequency trap or as a wall diffuser. Ideally, you can use it for broadband frequency acoustic treatment in different types of spaces.
Design Inspired by Renaissance thought.
The origin design idea is based on the idea of romanticism. It has the blend of religion & hedonism design style to show the open & passionate living environment.
Makes for a balanced absorbing surface like no other.
For a more balanced space, the Walleasear EQ50B can be easily customized according to your space requirements. It’s capable of handling broadband frequencies and can also control main reflections. You can use it in areas like churches, cinema rooms, studios, and halls, among others!
Model:
EQ50B Baroque
Selection of colors:
Base material:
Purely natural green fiber acoustic wool
Frame:
Sound reflection resistant design; anti-oxidization treatment; patented aluminum profile
Finish:
Linen double density composite acoustic cloth.
Acoustic Structure:
Three layers of base material in different densities wrapped in the airtight frame, forming an acoustic cavity to absorb sound in broadband frequency.
Eco-friendly:
Zero Formaldehyde emission; E0 standard
Common size & weight:
1800mm (H) x 600mm (W) x 50mm (T) – 6.2kg
1200mm (H) x 600mm (W) x 50mm (T) – 4.2kg
600mm (H) x 600mm (W) x 50mm (T) – 2.1kg
1800mm (H) x 300mm (W) x 50mm (T) – 3.1kg
1200mm (H) x 300mm (W) x 50mm (T) – 2.1kg
600mm (H) x 300mm (W) x 50mm (T) – 1.1kg
300mm (H) x 300mm (W) x 50mm (T) – 0.6kg
Installation:
Come with standard anti-resonance velcro fixing system.
Sound absorption coefficient:
Classic design combined with wide ranging sound absorption.
With a sound reflection resistant design, the EQ50Q Versailles is more than capable of absorbing a wide range of frequency. It’s a high-performance product that can no doubt meet your desired acoustic requirements for different purposes. The EQ50Q comes in a standard size for optimum reflection ideal for 1(Absorption):1(Diffusion).
Ideal for use in different settings.
The EQ50Q can expertly absorb a broad range of frequency and can also conveniently eliminate medium frequency echoes. Ideal for use on hallways, offices, entertaining rooms, and studios, this product is your best bet if you want a superb acoustic treatment that can effectively diffuses and absorbs sound for you.
Model:
EQ50Q Versailles
Selection of colors:
Base material:
Purely natural green fiber acoustic wool
Frame:
Sound reflection resistant design; anti-oxidization treatment; patented aluminum profile
Finish:
Linen double density composite acoustic cloth.
Acoustic Structure:
Three layers of base material in different densities wrapped in the airtight frame, forming an acoustic cavity to absorb sound in broadband frequency.
Eco-friendly:
Zero Formaldehyde emission; E0 standard
Common size & weight:
1800mm (H) x 600mm (W) x 50mm (T) – 6.2kg
1200mm (H) x 600mm (W) x 50mm (T) – 4.2kg
600mm (H) x 600mm (W) x 50mm (T) – 2.1kg
1800mm (H) x 300mm (W) x 50mm (T) – 3.1kg
1200mm (H) x 300mm (W) x 50mm (T) – 2.1kg
Installation:
Come with standard anti-resonance velcro fixing system.
Sound absorption coefficient:
Fusing an artistic look with standout acoustic capabilities.
True to its name, the EQ50M’s design is reminiscent of a roman pillar. It expertly combines a perfect artsy look with quality acoustic properties. It effectively controls sound wave reflections and is made of high-density porous material that’s capable of absorbing reverb no matter how wide your space is.
Maximized sound absorption for different settings.
With its back cavity structure and diversified acoustic cloth, it maximizes the absorption of sound waves reflected. It boasts of an increased one octave frequency volume (83 Hz at the lowest) which can be easily expanded using accessories that can extend its function.
Model:
EQ50M Roman Pillar
Selection of colors:
Base material:
Purely natural green fiber acoustic wool
Frame:
Sound reflection resistant design; anti-oxidization treatment; patented aluminum profile
Finish:
Linen double density composite acoustic cloth.
Acoustic Structure:
Three layers of base material in different densities wrapped in the airtight frame, forming an acoustic cavity to absorb sound in broadband frequency.
Eco-friendly:
Zero Formaldehyde emission; E0 standard
Common size & weight:
1800mm (H) x 600mm (W) x 90mm (T) – 7.8kg
1200mm (H) x 600mm (W) x 90mm (T) – 5.2kg
Installation:
Come with standard anti-resonance velcro fixing system.
Sound absorption coefficient:
Effective acoustic solution for controlling noise.
With its airtight frame that makes use of quality base materials, the EQ250 boasts of high-performing features for a wide variety of uses. It’s impressively equipped with a strong 3D 360 degree-sound absorbing surface that can be easily installed on the ceiling. It especially useful if you want to get rid of standing waves or any fluttering echoes.
Versatile design and cost-efficient treatment for wide spaces.
More than its high performance quality, it has zero formaldehyde emission and is also flame retardant. It’s convenient to install with its aluminum velcro fitting system and won’t be easily limited by your interior specifications since it can be conveniently installed on the ceiling. Best of all, it fits a wide range of spaces such as in places like conference rooms, entertainment rooms, and offices, to name just a few.
Model:
EQ250 Magic Cube
Selection of colors:
Base material:
Green fiber acoustic wool
Frame:
Soft framing knit.
Finish:
Linen double density composite acoustic cloth.
Acoustic Structure:
An airtight frame wrapped around base material in different densities.
Eco-friendly:
Zero Formaldehyde emission; E0 standard
Common size & weight:
1200mm (H) x 250mm (W) x 100mm (T) – 3kg
Installation:
Come with standard anti-resonance velcro fixing system.
Sound absorption coefficient:
